AVK SUPA-GIB END CAP, DN350-DN600

SS316, A4 Fasteners, NBR Seal, PN16

AVK Wingfield Plant

Contact

AVK Australia Civil

559A Grand Junction Road Wingfield SA 5013 Sales and Technical enquiry

Supa-gib blank end for water and sewer application to max. 60c

Dedicated supa-gib blank end for use on Cast Iron, Ductile Iron, Steel, PVC-U, PVC-M, PVC-O, AC and Copper pipes.

Manufactured by AVK WANG

Variant 605/52-001
Connection: Supa Coupling
Material: Stainless Steel
DN: DN350 - DN600
PN: PN16

Features

  • For water and sewer applications to max 60oC
  • Stainless Steel construction
  • Angular deflection of ± 3 degrees (total 6 degrees)
  • 16 bar / 160 meters allowable operating pressure (AOP)
  • Non restrained

Downloads

Datasheet
Certificate(s)
Installation, Operation & Maintenance

Reference nos. and dimensions:

Scroll for more info
AVK ref. no. DN
mm		 Product
PN Class		 Seal range
mm		 A
mm		 B
mm		 No. of
bolts
605-5-394-1 350 PN16 370-394 527 220 8
605-5-394-2 350 PN16 370-394 527 220 8
605-5-404-1 375 PN16 380-404 537 220 8
605-5-404-2 375 PN16 380-404 537 220 8
605-5-420-2 375 PN16 396-420 553 220 8
605-5-434-2 375 PN16 410-434 567 220 8
605-5-460-2 400 PN16 436-460 593 220 10
605-5-490-2 450 PN16 466-490 623 220 10
605-5-512-2 450 PN16 488-512 645 220 10
605-5-522-2 450 PN16 498-522 655 220 10
605-5-534-2 500 PN16 510-534 667 220 12
605-5-654-2 600 PN16 630-654 687 220 12
605-5-672-2 600 PN16 648-672 805 220 14
Enquiry
Scroll for more info

Components

1. Body Stainless steel 316
2. Flange Stainless steel 316
3. Nut Stainless steel A4, PTFE coated
4. Washer Stainless steel 316
5. Bolt Stainless steel A4
6. Seal NBR rubber

Standards

  • All materials AS/NZS 4020 compliant
  • Manufactured in accordance with AS/NZS 4998
